Crimper PCM
Four point crimper for loose, turned contacts (AWG 28 � 12)
The pneumatic driven crimper is specifically designed to crimp loose turned contacts. In the range of 0.08 up to 4 mm2 (AWG 28 � 12) wires and contacts can be crimped. A 4/8-indent crimp corresponding to SAE 22520 is standard. The crimping-depth can be adjusted manually in 10 ?m steps. The machine is equipped with standard crimping tool kit, the crimper can be easily adapted to various contacts. Brackets for optimized infeed and centering of the wire are optionally available.
Options
� Other crimp form: 4-indent
� Brackets for optimized infeed and centering of the wire
Technical data
PCM
Crimping range
0,08 � 4 mm� (AWG 28 � 12)
Crimping form
4/8-indent / 4-indent
Cycle time approx.
1 s
Air pressure
5,5 bar (80 psi)
Dimensions
(B x T x H) 140 x 260 x 210 mm
(w x d x h) (5.5 x 10.2 x 8.3 in.)
Weight
8 kg (17.64 lbs)
